P3 Gauge – VW Golf / GTI/R MK8/8.5

P3 – OBD2 Vent Multi-Gauge V3 – VW Golf / GTI / R MK8 / MK8.5

Form and Function

Every P3 Gauge is built just for your car. It fits perfectly—like it was born there.

Stealthy. Stylish. Smart.

In one sleek display, you get real-time access to everything that matters: boost pressure, engine temperatures, performance timers, diagnostic reading/clearing, and more. All from the included diagnostics port connection or optional add-on sensors.

It’s easy to install, simple to use, and made to last.

Every unit is built to order, hand-assembled, and developed entirely in-house—not by a huge corporation, but by a small team who loves cars as much as you do.

Gauge Modes / Readings

We designed the P3 Gauge to read the most important data from your specific vehicle for true plug-and-play installation. With a single OBD port connection, you’ll be up and running in minutes. Advanced tuners can add additional sensors or even run the gauge in analog-only mode if desired.

OBD Port Data (CANbus Input)

• Boost Pressure
• Coolant Temperature
• Engine Oil Temperature
• Air/Fuel Ratio (AFR or Lambda)
• Vehicle Speed (Calibrated or Raw)
• Intake Air Temperature (IAT)
• Throttle Angle
• Ignition Timing
• Engine RPM (with programmable shift light)
• Exhaust Gas Temperature (EGT)
• Battery Voltage
• Acceleration Timers (0–60, 0–100, 60–130)
• Braking Timers (60–0, 100–0)
• Read & Clear Diagnostic Trouble Codes (DTCs)

Optional Analog Inputs

Optional but powerful. The P3 Gauge supports up to three additional analog sensor inputs, plus a dedicated input for automatic display dimming.

Analog Boost Input
• Supports the optional P3 Analog Boost Sensor
• Reads up to 80 PSI
• Ideal for high-boost or aftermarket forced-induction setups

2 × Universal 0–5V Inputs
• Two independent, configurable analog inputs
• Compatible with a wide range of aftermarket sensors
• Near-infinite customization and tuning possibilities

Dimmer Voltage Detection Input
• Configure the gauge to d.On.A mode
• Any signal over 1V triggers display dimming
• Perfect for tapping into factory interior lighting

Vehicle Fitment – P3 OBD2 Vent Multi-Gauge V3 (MK8 / MK8.5 Platform)
