034 Motorsport - Dynamic+ Lowering Springs - Audi B8/B8.5 Q5/SQ5 - 034-404-1009

034 Motorsport – Dynamic+ Lowering Springs

For Audi B8/B8.5 Q5 & SQ5

034Motorsport Dynamic+ Lowering Springs for the Audi B8/B8.5 Q5 and SQ5 were engineered in-house to deliver a perfect balance of ride comfort, chassis control, and aggressive stance. Designed as a no-compromise spring solution, these springs enhance handling, reduce body roll, and maintain near-OEM comfort levels while transforming the vehicle’s aesthetics.

These springs were tested extensively on 034Motorsport's own B8 Q5 and B8.5 SQ5 development vehicles across thousands of kilometres of commuting, backroad driving, and track evaluation. The result is a spring set that works harmoniously with factory dampers, delivering dependable performance without bottoming out or compromising suspension travel.

034Motorsport follows a strict engineering principle: never chase maximum drop at the expense of proper damper function, suspension geometry, or daily drivability. Dynamic+ Springs provide a functional, performance-focused drop with a slight positive rake to maintain load capacity and prevent the rear from sagging under cargo.

All Dynamic+ Springs are manufactured in the USA at an ISO 9001 certified facility, ensuring unmatched quality and long-term reliability.

Features

• Improved handling response and chassis balance

• Reduced body roll and understeer

• Maintains excellent ride quality and comfort

• Optimised ride height to retain ground clearance and damper performance

• Slight positive rake to preserve load handling

• High-strength, lightweight spring construction

• Compatible with Audi Adaptive Suspension

• Shot-peened and powder-coated for corrosion resistance

• Tight tolerance manufacturing: ±5% (industry standard ±10%)

• Designed, tested, and engineered by 034Motorsport

• Made in the USA at an ISO 9001 certified facility

Ride Height (Lowering Amount)

Provides approximately 2.5” to 3.5” of lowering

• Front: 60–80mm lower

• Rear: 60–80mm lower

Lowering variance depends on Q5 vs SQ5, wheel width, offset, tyre rolling diameter, and load. The springs are engineered to always provide a slightly lower front end for ideal handling and aesthetic balance.

Effective Spring Rates

Factory Springs

• Front: 382 lbs/in (linear)

• Rear: 213 lbs/in (linear)

034Motorsport Dynamic+ Springs

• Front: ~10% increase — 275/431 lbs/in (dual-rate)

• Rear: ~15% increase — 174/248 lbs/in (dual-rate)

Dual-rate springs allow excellent cruising comfort with firmer support under dynamic load.

FITMENT TABLE
